| DATA SHEET | EU | US |
|---|---|---|
| ENGINE | 205 KW | 275 HP |
| MAST WORKING STROKE | 7500-10500 mm | 24,5-34,4 ft |
| MAST PULL-PUSH | 10-20 Kn | 22500-44900 lbf |
| WEIGHT | 25000-28000 Kg | 55000-62000 lb |
| WIDTH | 2450 mm | 8,03 ft |
| TORQUE ROTARY | 1200-3200 daNm | 8850-23600 lb ft |
| RPM ROTARY | 150-1050 | 150-1050 |
| MAX CLAMP DIAMETER | 324-435 mm | 12,7-17,1 in |
