GALLERY
| TECHNICAL DATA | ||
|---|---|---|
| ENGINE | 19 KW | 25 HP |
| MAST WORKING STROKE | 1250 mm | 4.1 ft |
| RETRACT FORCE | 15 Kn | 3380 lbf |
| WEIGHT | 1100 kg | 2300 lb |
| WIDTH | 650mm (opt.780-900) | 1,9ft /opt.2,55-2,95 |
| TORQUE ROTARY | 90-350 daNm | 660-2580 lb ft |
| RPM ROTARY | 110-450 | 111-450 |
| MAX CLAMP DIAMETER | 160 mm | 6,3 in |
